Rangemaster 63040 90cm Classic Chimney Cooker Hood in Black with Brass Rail - CLAHDC90BB/

Rangemaster Classic 90cm Chimney Hood – Black with Brass Trim

The Rangemaster Classic chimney hood blends timeless style with everyday practicality. Finished in striking black with elegant brass trim and a full-length towel rail, it brings a touch of traditional charm to your kitchen while delivering powerful extraction performance.

Available in a range of sizes and colours, this 90cm model is ideal for larger hobs and cookers. Whether you're using it in ducted or recirculating mode, it’s equipped to efficiently remove steam, grease, and odours from the air. A charcoal filter is included for recirculation setups.

Key Features:

• Classic Styling: Black finish with brass trim and full rail
• Extraction Rate: 240–460 m³/h
• Extraction Type: Suitable for ducted and recirculating installation
• Charcoal Filter Included: Yes – ideal for re-circulation setup
• Design Options: Available in 3 sizes and 3 colourways

Product Code: 63040

Dimensions (HxWxD): 1020 x 898 x 490 mm

Warranty: 2 years parts and labour

Add classic flair and excellent performance to your kitchen with this standout 90cm Rangemaster hood.

Brand

• Rangemaster

Performance

• Flow Rate at BEP: 235.0

• Static Pressure at BEP: 168

• Electric Power Input at BEP: 136.0 W

• Grease Filtering Efficiency (GFE): 75.1%

Air Flow Rates

• Setting 1 (Working Point): 240 m³/h

• Setting 1 (Free Blowing): 250 m³/h

• Setting 2 (Working Point): 330 m³/h

• Setting 2 (Free Blowing): 350 m³/h

• Setting 3 (Working Point): 440 m³/h

• Setting 3 (Free Blowing): 460 m³/h

Noise Levels (Sound Power dB(A))

• Setting 1: 55

• Setting 2: 64

• Setting 3: 69

Lighting

• Effectiveness of Hob Light: 800

Fiche 65/2014

• Trade Mark: Rangemaster

• Model: CLAHDC90BB/

• Annual Energy Consumption: 91.7 kWh/year

• Energy Efficiency Class: D

• Fluid Dynamic Efficiency: 8.10

• Fluid Dynamic Efficiency Class: E

• Lighting Efficiency: 80.0

• Lighting Efficiency Class: A

• Grease Filtering Efficiency: 75.1

• Grease Filtering Efficiency Class: C

• Air Flow (Normal Use): 240 / 440 m³/h

• Air Flow (Boost): Not specified

• Noise Emissions (Normal Use): 55 / 69 dB(A)

• Noise Emissions (Boost): Not specified

Design & Features

• Colour: Black (Brass)

• Chrome Badge & Rail: Yes

• Charcoal & Aluminium Filters: Yes

• Recirculating & Extraction: Yes

• Control Speed: 3

Dimensions

• Chimney Height: 495–780 mm

• Depth: 490 mm

• Height: 1020 mm

• Width: 898 mm
